Dragon’s Treasure: Faceting Design Diagram


Successful tips and guide on Faceting Designs. Faceting Design Diagram by Jeff R. Graham that presents various cuts, this one is called "Dragon's Treasure".

0

Quartz (Amethyst, Citrine, Ametrine, Smokey, Rose)

Dragons Treasur Jeff Graham Facet Design2

Dragons Treasur Jeff Graham Facet Design1

Dragon's Treasure (BEAD33.JRG)
By Jeff R. Graham
Copyright 2007
Angles for R.I. = 1.54
162 facets
16-fold, mirror-image symmetry
96 index
L/W = 1.000 T/W = 0.104 T/L = 0.104
H/W = 1.336
Vol./W^3 = 0.526

PAVILION

CROWN

Addition # 14 - NOTE: A temporary girdle can be cut using the P1 settings. This is nice and easy to cut. It works well as a medium-sized bead and I like about any material saturation.

Detailed faceting instructions by Jeff Graham available at The Rock Peddler


Jeff R. Graham

The late Jeff Graham was a prolific faceter, creator of many original faceting designs, and the author of several highly-regarded instructional faceting books such as Gram Faceting Designs.
